| Bearing No | Dimensions | KG | Load Ratings | Limiting Speed | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| NEW | OLD | d | D | B | C | T | Weight | cr | cor | Oil | Grease |
| 30208X/YB | 137808E | 39.000 | 68.000 | 18.500 | 37.000 | 37.000 | 0.432 | 76 | 68 | 5900 | 4900 |
| 352208X | 97508E | 40.000 | 80.000 | 23.000 | 43.500 | 55.000 | 1.120 | 88 | 37 | 4500 | 3800 |
| 352211X | 97511E | 55.000 | 100.000 | 25.000 | 42.500 | 56.000 | 1.824 | 189.5 | 277 | 3500 | 2600 |
| 352212X | 97512E | 60.000 | 110.000 | 28.000 | 54.500 | 66.000 | 2.529 | 215 | 205 | 3300 | 2200 |
| 352214X | 97514E | 70.000 | 125.000 | 31.000 | 61.500 | 74.000 | 3.661 | 272 | 268 | 2800 | 2000 |
| 352216X | 97516E | 80.000 | 140.000 | 33.000 | 63.500 | 78.000 | 4.465 | 320 | 315 | 2400 | 1800 |
| 352218X | 97518E | 90.000 | 160.000 | 40.000 | 77.000 | 94.000 | 7.342 | 440 | 452 | 2000 | 1600 |
| 352022 | 110.000 | 170.000 | 38.000 | 68.000 | 86.000 | 6.718 | 807 | 420.1 | 1800 | 1300 | |
| 55206/5544D | 52.388 | 112.712 | 26.909 | 46.038 | 65.088 | 2.732 | 176 | 155 | 3600 | 2400 | |
| 64450/64700D | 114.300 | 177.800 | 41.275 | 69.850 | 92.075 | 7.450 | 232 | 375 | 2600 | 1900 | |
| HM821547/HM821511D | 99.979 | 196.850 | 46.038 | 74.422 | 103.378 | 10.330 | 430 | 510 | 4800 | 3800 | |
| TRB1160/42 | 42.000 | 76.000 | 19.500 | 39.000 | 39.000 | 0.711 | 96 | 125 | 4100 | 2900 | |
| 28985/XC2279DB | 60.325 | 104.775 | 25.400 | 44.450 | 55.560 | 1.820 | 181 | 271 | 3600 | 2500 | |
| 495W/493D | 82.550 | 136.525 | 29.769 | 53.975 | 69.850 | 3.639 | 265 | 394 | 2600 | 2000 | |
